250°C High Temperature Resistance 6 8 10 12 Gauge PTFE Insulated Wire with 600V Rated Voltage for Aircraft Wiring

200
MOQ
250°C High Temperature Resistance 6 8 10 12 Gauge PTFE Insulated Wire with 600V Rated Voltage for Aircraft Wiring
Kenmerken Galerij Productomschrijving Verzoek om een Citaat
Kenmerken
Specificaties
Geleidingsmateriaal: Koper
Isolatiemateriaal: PTFE
Type geleider: Gestrand
Draadmeter: 6 gauge, 8 gauge, 10 gauge, 12 gauge
Nominale spanning: 鎮ㄨ鎵剧殑璧勬簮宸茶鍒犻櫎銆佸凡鏇村悕鎴栨殏鏃朵笉鍙敤銆
Kernnummer: 1 kern, 2 kern
Temperatuurbereik: -65 ~+200ºC, -80 ~+250ºC
Isolatiedikte: 0,3 mm, 0,32 mm, 0,35 mm, 0,45 mm, 0,55 mm, 0,68 mm
Buitendiameter: 0,9 mm tot 3,6 mm
Gelijkstroom-weerstand: 383Ω/km tot 6,4Ω/km
Geleidersconstructie: 7/0,08 mm tot 37/0,32 mm
Nominale sectie: 0,05 mm² tot 3 mm²
Kleuropties: Rood, oranje, zwart, groen, blauw, etc.
Vlam achterlijk: Ja
Olieweerstand: Ja
Markeren:

250°C High Temperature Resistance PTFE Insulated Wire

,

6 8 10 12 Gauge High Temperature Wire

,

600V Rated Voltage High Temperature Cable
Basis informatie
Plaats van herkomst: CHINA
Merknaam: Sanco cable
Modelnummer: AF 250, AFP 250
Betalen & Verzenden Algemene voorwaarden
Productomschrijving
1 Core 2Core 6 8 10 12 Gauge 250°C High Temperature Wire Cable
250°C High Temperature Wire Cable
Applications

This 250°C high temperature wire is suitable for:

  • Aircraft wiring and electrical equipment
  • Telecommunication equipment and instrumentation circuits (AC rated voltage 600V and below)
  • Temperature compensating wire, low temperature-resist wire, high temperature heat wire
  • Aging-resistance and fire-resist applications
  • Household appliances including air-conditioning, microwave ovens, electric cookers, heaters, ovens, and lamps
Product Features
  • Excellent corrosion resistance with minimal organic impurity melting
  • Oil-resistant, strong acid/alkali resistant, and oxidant-resistant
  • Superior electrical insulation with high voltage and moisture resistance
  • Flame-retardant and anti-aging properties for long service life
Specifications
  • Available Colors: Red, yellow, blue, green, white, black, orange, purple, brown
  • Insulation: FEP, PFA (250°C), PTFE (250°C)
  • Conductor: Tinned copper, silver-plated copper, or bare copper
  • Temperature Range: -65°C to +250°C
  • Rated Voltage: 600V and below
250°C High Temperature Resistance 6 8 10 12 Gauge PTFE Insulated Wire with 600V Rated Voltage for Aircraft Wiring 1
Product Types
Type Description
AF-200 Silver coated copper core high temperature FEP cable
AF-200-1 Tinned copper core FEP insulation cable
AFP-200 Tinned/silver coated copper core FEP insulated shielding cable
AFS-200 Tinned/silver coated copper core FEP insulated stranded cable
AFSP-200 Tinned/silver coated copper FEP insulated stranded shielding cable
Type Description
AFR-200 Copper conductor PTFE film insulation installation wire
AFR-250 Silver coated copper conductor PTFE film insulation installation wire
AFP Copper conductor PTFE film insulation screen installation wire
AFP-1 Silver coated copper conductor PTFE film insulation screen installation wire
Technical Specifications
Wire AWG Nominal Section (mm²) Conductor Construction (No/mm) Insulation Thickness (mm) Outer Diameter (mm) D.C. Conductor Resistance at 20°C (Ω/km)
0.05 10/0.08 0.3 0.9 383 | 370
30AWG 0.06 7/0.10 0.3 0.9 348 | 339
28AWG 0.08 7/0.12 0.3 0.96 286 | 280
0.1 7/0.14 0.3 1.02 157 | 150
Company Information

Factory: Shenzhou Special Cable is a reputed manufacturer of military and consumer cables. Our main products include high temperature wires, PTFE/FEP cables, silver plated copper cables, rubber cables, welding cables, and more.

Team: We have advanced R&D staff, professional transport team, high-quality installation team, talented technicians, and dedicated sales departments to meet customer demands.

250°C High Temperature Resistance 6 8 10 12 Gauge PTFE Insulated Wire with 600V Rated Voltage for Aircraft Wiring 2

Workshop: 9 production lines with monthly capacity of 90,000m. About 250 production workers with annual capacity of RMB20 million. Advanced test equipment for electrical, chemical and mechanical properties.

Warehouse: 600+ square meters finished product storage. Also engaged in low smoke zero halogen compounds, XLPE compound, and soft PVC compound production.

250°C High Temperature Resistance 6 8 10 12 Gauge PTFE Insulated Wire with 600V Rated Voltage for Aircraft Wiring 3
Quality Assurance

We focus on quality and carry out strict quality control throughout the manufacturing process. We guarantee repair, replacement, or return for any products with quality issues during manufacture.

250°C High Temperature Resistance 6 8 10 12 Gauge PTFE Insulated Wire with 600V Rated Voltage for Aircraft Wiring 4
Why Choose Us
  • Stable supplier for China's aerospace and military
  • 21 years of cable production experience
  • Self-produced cable compounds ensure superior quality
  • Competitive pricing for global customers
250°C High Temperature Resistance 6 8 10 12 Gauge PTFE Insulated Wire with 600V Rated Voltage for Aircraft Wiring 5
Our Service
  • Free technical consultation before, during, and after sales
  • Free samples and design services
  • Special monitoring during manufacture process
  • 100% free insurance for internal transportation
  • OEM & ODM welcome
  • Small orders accepted
Packing & Shipping
250°C High Temperature Resistance 6 8 10 12 Gauge PTFE Insulated Wire with 600V Rated Voltage for Aircraft Wiring 6
  • 100m/coil with non-woven bag
  • 200m/roll with film
  • 500m with wooden drum
  • 800m with wooden iron drum
  • Fumigation package and certificate available
  • Shipping by sea, train, express or customer preference
FAQ
Q: Are you a manufacturer or trading company?

A: We are a professional manufacturer of military and consumer cable wire and cable compound, located in Hunan Province, China.

Q: What is your company's strengths?

A: We are a stable supplier for China's aerospace and military with 21 years experience. Our self-produced cable compounds ensure superior quality and competitive pricing.

Q: How do you guarantee your product quality?

A: Quality is our priority with strict control from design to finished product inspection.

Q: What's the warranty of your products?

A: We provide 1 year complete warranty service with unconditional replacement or return for quality issues.
